Description
| Input | Voltage Range: 162-290VAC (Single boost), 140-300VAC (Double boost) Frequency: 50Hz/60Hz (Auto-sensing) Phase: Single + GND |
|---|---|
| Output | Voltage Range: 220-240VAC Frequency: 50Hz ±1% (Battery mode) Waveform: Simulated sine wave (Battery mode), Sine wave (AC mode) Transfer Time: 2ms typical |
| Battery | Type: 12V/8.2Ah x 1 Backup Time: 8-20 mins depending on load Recharge Time: 2-4 hours recover to 90% capacity Short Circuit Protection: Yes (Line mode & battery mode) Surge Protection: Yes |
| Protection/Monitoring | Alarm: Audible & Visual, Line mode: 100-120% 1 min change to fault mode, Overload Protection: >120% change to fault mode immediately, Battery mode: 100-120% 1 min change to fault mode, >120% change to fault mode immediately Intelligent Battery Management: Prevent overcharging of battery, Protect battery and prolong battery life |
| Indicator | Display: LED/LCD Optional Alarm: Batt. Mode, low battery, overload, fault, etc. RS232: Optional |
| Interface | USB port: Optional RJ45/RJ11: Optional Auto Recharge: Yes |
| Management | Auto Restart: Yes Power Management Software: Yes Noise Level: <40dB Temperature: 0°C-40°C |
| General | Humidity: 0-90% Power Factor: Up to 0.7 Built-in AVR: TRUE Full AVR (3 steps) |
| Physical | Dimension (DxWxH): 286 x 96 x 138mm Weight: 4.3 kg |
